Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations

Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations
Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations

大画像 :  Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations

商品の詳細:
起源の場所: 中国
ブランド名: HYDROTU
モデル番号: HLA515C-WJ
書類: Enquiry sheet.doc
お支払配送条件:
最小注文数量: 1セット
受渡し時間: 5～10ヶ月
支払条件: LC、T/T
連絡先

Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations

説明
定格ヘッド: 20-400m Poweroutput: 100kWから10MWまで
流量範囲: 低流量から高流量まで ランナー材料: ステンレス鋼
定格速度: 500-1000r/min 流れ: 0.15〜10m3/s
ガイドベーン: ステンレス鋼 興奮モード: ブラシレス
ハイライト:

Stainless Steel Runner Francis Hydro Turbine

,

20-400m Rated Head Francis Turbine

,

Horizontal Shaft Hydropower Turbine

Francis Hydro Turbine for Horizontal Shaft Installations
HYDROTU Francis hydro turbines deliver exceptional performance, reliability, and adaptability for medium-head hydropower applications worldwide. Continuous optimization is driven by advanced hydrodynamic research and decades of operational experience.
Application Scope
Designed for medium head conditions up to 300 meters and large water flow scenarios, these turbines leverage unique hydraulic characteristics to create high-speed, compact units capable of achieving maximum power outputs.
Available Solutions
  • Custom Francis Turbines: For small to medium-scale hydropower plants with high quality requirements, adaptable to water head conditions up to 300 m
  • Standard Francis Turbines: Cost-effective standardized designs for small to medium-sized hydropower projects with stable operational conditions
  • Horizontal Shaft Francis Turbines: Optimized for low-to-medium head small hydropower applications with flexible installation requirements
  • Small Francis Turbines: Modular horizontal units for small hydro sites (head range 20-300 m, flow 0.25-3.80 m³/s), with output up to 10,000 kW, featuring pre-assembled components for rapid on-site installation
Technical Specifications
Parameter Specification
Maximum Output Up to 10 MW
Maximum Head 300 m
Maximum Runner Diameter 2 m
Operational Flexibility Adaptable to variable flow and head conditions with stable performance under partial load operation
HL Series Small Francis Turbine Single regulation via guide vanes, directly coupled synchronous generator, optimized steel components and auxiliary systems
Design & Technology Advantages
Advanced Hydraulic Engineering
Integration of numerical development methods with computer-aided manufacturing processes, including high-precision flow simulations and coupled hydro-mechanical calculations for optimum hydraulic performance and minimal energy loss.
Grid Stability Support
State-of-the-art designs engineered to meet modern grid demands with enhanced operational flexibility and rapid response capabilities to power fluctuations, ideal for hybrid energy systems integrating wind and solar power.
Customization & Standardization Balance
HYDROTU offers fully customized solutions for small to medium-scale hydropower projects while providing cost-effective standardized Francis turbine packages, ensuring optimal economic efficiency and performance matching.
Global Reliability & Quality Assurance
HYDROTU Francis turbines operate worldwide across multiple markets. Manufacturing and quality management systems comply with international ISO standards for quality, environmental protection, and occupational health & safety.
Full Life-Cycle Support
Backed by comprehensive manufacturing and service network, HYDROTU provides complete support for Francis turbine projects—from initial design and custom manufacturing to on-site installation, commissioning, maintenance, and retrofitting. Professional service teams ensure rapid response to customer needs, maximizing turbine availability and operational efficiency.
Sustainable Hydropower Solution
As a core product of HYDROTU's sustainable hydropower portfolio, our Francis turbines deliver clean, renewable energy with minimal CO₂ footprint. The compact design reduces civil engineering costs and environmental impact, while the long service life and high efficiency ensure economic viability and ecological sustainability for hydropower projects of all sizes.
Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations 0
Stainless Steel Runner Francis Hydro Turbine with 20-400m Rated Head for Horizontal Shaft Installations 1

総格付け

4.5
このサプライヤーに対する50件のレビューに基づいています

評価のスナップショット

すべての評価の分布は以下の通りです
5 星
50%
4 星
50%
3 星
0%
2 星
0%
1 星
0%

すべてのレビュー

M
m*l
Philippines Feb 5.2026
役に立つ (10)
This Kaplan Turbine equipped with stainless steel blades is a reliable and high-performance solution. The stainless steel construction provides strong resistance to wear and cavitation, while the overall design delivers efficient power generation. It has proven to be a cost-effective and low-maintenance choice for our hydropower unit.
H
HULUSI
Turkey May 20.2021
役に立つ (15)
HYDROTU has professional service team, From the initial preliminary consultation, personalized unit design and type selection, to on-site installation, commissioning, and later operation and maintenance, their professional team provided thoughtful and efficient support.
